Description
Product details
Switzer Digital Pressure Gauge. Dial: 100mm Range: 0....700 cmWC & 0....400 Bar. Stainless steel case for outdoor operating conditions Accuracy ±0.5% of span Battery operation (3 × 1.5V AA cell); Battery life: Approx. 1000 hours Backlight option for dark environments Pressure Units: Bar, Psi, Kg/cm², kPa, Mpa, cmWC, mmWC, mbar
![Make: WIKA Flow Switch, for Fire Sprinkler Wet Systems
Model: Model FSFD 8 / Line Size: 200mm
Die cast Aluminium housing (EN AC-46000), UL and FM approved
Flow rate / Sensitivity: 4...10 GPM (15...38 LPM)
Service pressure: 268 psi [18.5 bar]*
Maximum surge: 18FPS (5.5m/s)
Operating temperature: 0...68°C [32°F...154°F]
Environment protection: IP 56/NEMA 4 rating suitable for indoor & outdoor applications; Switching Function: 2*SPDT (Form C)
Electrical rating: 10A 125/250 VAC; 2A 30VDC Res.
Horizontal/vertical mounting along the direction of arrow mark on cover & saddle;
Refer Operating instructions 83795208 for compatibles pipes, installation and maintenance.
*With UL346 the operating pressure is limited to 175 psi[12bar] for pipe size 8](images/service/no-product-details.png)
